KARB R KALIPÇI FRE ELERİ

J 60 KONİK K 90 KONİK
TİPİ TİPİ

Ø (mm) Ø (mm) Ø 1 (mm)
1 (mm) (mm)
L (mm) L (mm)
KODU Ø Ø 1 L 1 L KO L İ KODU Ø Ø 1 L 1 L KO L İ
6 mm SAPLI 6 mm SAPLI
DWFJ08 8.0 mm 6 6.0 54 8,00 25 DWFK10 10.0 mm 6 4.7 52 8,70 25
DWFJ10 10.0 mm 6 8.0 55 8,70 25 DWFK13 12.0 mm 6 6.3 54 10,50 25
DWFJ13 12.0 mm 6 11.0 59 10,50 25 DWFK16 16.0 mm 6 8.0 55 17,50 25
DWFJ16 16.0 mm 6 14.5 62 17,50 25 DWFK19 19.0 mm 6 9.5 58 19,00 25
DWFJ19 19.0 mm 6 17.5 66 21,00 25 DWFK25 25.0 mm 6 12.7 60 28,00 25

N DEMİR DIŞI MALZEMELER için KARBÜR KALIPÇI FREZELERİ
TİPİ TERS KONİK ALUMİNYUM, BAKIR, KURŞUN, KALAY, PLASTİK, FİBER ve PLEKSİ için
A SİLİNDİRİK DÜZ
Ø (mm) TİPİ
L 1 (mm)
L (mm)
Ø (mm) Ø 1 (mm)
KODU Ø Ø 1 L 1 L KO L İ L 1 (mm) L (mm)
3 mm SAPLI - KOMPLE KARBÜR
DWF3KN02 2.5 mm 3 3.0 38 4,90 10
DWF3KN03 3.0 mm 3 4.0 38 4,90 10
KODU Ø Ø 1 L 1 L KO L İ
3 mm SAPLI
DWF3N05 5.0 mm 3 6.0 44 4,40 10 DWFAA08 8.0 mm 6 20 65 13,80 25
DWF3N06 6.3 mm 3 6.0 44 4,80 10 DWFAA10 10.0 mm 6 20 65 16,00 25
DWFAA12 12.0 mm 6 25 70 23,50 25

TEK KANALLI KOMPLE KARBÜR KALIPÇI FREZELER C SİLİNDİRİK OVAL BAŞLI

TİPİ
Ø 3.0 mm
L 38 mm KO L İ L İ KO 10
A DWFKK3A C DWFKK3C Ø (mm) Ø 1 (mm)
TİPİ 4,80 TİPİ 4,80 L 1 (mm) L (mm)

KODU Ø Ø 1 L 1 L KO L İ
DWFAC08 8.0 mm 6 20 65 13,00 25
DWFAC10 10.0 mm 6 20 65 16,00 25
DWFAC12 12.0 mm 6 25 70 25,00 25

D DWFKK3D E DWFKK3E
TİPİ 4,80 TİPİ 4,80 F KAVİSLİ SİLİNDİR
TİPİ

Ø (mm) Ø 1 (mm)
L 1 (mm)
L (mm)

F DWFKK3F M DWFKK3M KODU Ø Ø 1 L 1 L KO L İ
TİPİ 4,80 TİPİ 4,80
DWFAF08 8.0 mm 6 20 65 11,50 25
DWFAF10 10.0 mm 6 20 65 14,50 25
DWFAF12 12.0 mm 6 25 70 20,50 25
CONE
CNFAF12 12.0 mm 6 25 70 15,00 25
