81& .,/$98=/$5

3$5‰$/, 7$.,0 (/ .,/$98=8 81& 12 621 .,/$98= 81&
DIN-351 Ø 1 (mm) A (mm) DIN-351/C
Ø (mm)
HSS-M2AL HSS-M2AL
L 1 (mm)
Ø 1 (mm) A (mm)
L (mm)
Ø (mm)
L 1 (mm)
L (mm)
60 °
P
A(6-8)
60 °
P
D(3.5-5)
60 °
60 ° P
P
C(2-3) C(2-3)
Ø (mm) Ø (mm)
KODU Ø x P L L 1 Ø 1 A KODU Ø x P L L 1 Ø 1 A
MKC351316 UNC 3/16" x 24 24 50 16 6 4.9 3.6 8,10 MKC351S316 UNC 3/16" x 24 24 50 16 6 4.9 3.6 3,20
MKC35114 UNC 1/4" x 20 50 16 6 4.9 5.1 8,80 MKC351S14 UNC 1/4" x 20 50 16 6 4.9 5.1 4,30
MKC351516 UNC 5/16" x 18 18 56 22 6 4.9 6.5 10,60 MKC351S516 UNC 5/16" x 18 18 56 22 6 4.9 6.5 5,70
MKC35138 UNC 3/8" x 16 63 20 7 5.5 7.9 12,20 MKC351S38 UNC 3/8" x 16 63 20 7 5.5 7.9 7,20
MKC351716 UNC 7/16" x 14 14 63 20 8 6.2 9.3 15,00 MKC351S716 UNC 7/16" x 14 14 63 20 8 6.2 9.3 8,90
MKC35112 UNC 1/2" x 13 70 22 9 7.0 10.6 17,50 MKC351S12 UNC 1/2" x 13 70 22 9 7.0 10.6 9,30
MKC351916 UNC 9/16" x 12 12 70 22 9 9.0 12.1 19,00 MKC351S916 UNC 9/16" x 12 12 70 22 9 9.0 12.1 10,60
MKC35158 UNC 5/8" x 11 70 22 12 9.0 13.5 22,00 MKC351S58 UNC 5/8" x 11 70 22 12 9.0 13.5 12,20
MKC35134 UNC 3/4" x 10 10 80 22 14 11.0 16.5 39,00 MKC351S34 UNC 3/4" x 10 10 80 22 14 11.0 16.5 15,00
MKC35178 UNC 7/8" x 9 80 22 18 14.5 19.3 52,00 MKC351S78 UNC 7/8" x 9 80 22 18 14.5 19.3 19,00
MKC3511 UNC 1" x 8 8 90 22 18 14.5 22.0 76,00 MKC351S1 UNC 1" x 8 8 90 22 18 14.5 22.0 27,50

'ž= .$1$/ 0$.ð1( .,/$98=8 81& r +(/ð6 .$1$/ 0$.ð1( .,/$98=8 81&
DIN-2183/C DIN-2183/C
A (mm)
Ø 1 (mm) A (mm) Ø 1 (mm)
HSS-M2AL HSS-M2AL 35 °
Ø (mm)
Ø (mm) L 1 (mm)
L 1 (mm)
L (mm)
L (mm)

60 ° 60 °
P P
C(2-3) C(2-3)

Ø (mm) Ø (mm)
KODU Ø x P L L 1 Ø 1 A KODU Ø x P L L 1 Ø 1 A
MK2183C14 UNC 1/4" x 20 20 80 19 4.5 3.4 5.2 5,20 MK2183H14 UNC 1/4" x 20 20 80 12 4.5 3.4 5.2 5,20
MK2183C516 UNC 5/16" x 18 90 22 6.0 4.9 6.6 5,80 MK2183H516 UNC 5/16" x 18 90 14 6.0 4.9 6.6 5,90
MK2183C38 UNC 3/8" x 16 16 100 24 7.0 5.5 8.0 6,50 MK2183H38 UNC 3/8" x 16 16 100 16 7.0 5.5 8.0 7,80
MK2183C716 UNC 7/16" x 14 100 24 8.0 6.2 9.4 6,80 MK2183H716 UNC 7/16" x 14 100 16 8.0 6.2 9.4 8,00
MK2183C12 UNC 1/2" x 13 13 110 29 9.0 7.0 10.8 8,50 MK2183H12 UNC 1/2" x 13 13 110 20 9.0 7.0 10.8 8,80
MK2183C916 UNC 9/16" x 12 110 30 11.0 9.0 12.2 8,70 MK2183H916 UNC 9/16" x 12 110 22 11.0 9.0 12.2 9,60
MK2183C58 UNC 5/8" x 11 11 110 32 12.0 9.0 13.5 9,50 MK2183H58 UNC 5/8" x 11 11 110 22 12.0 9.0 13.5 11,00
MK2183C34 UNC 3/4" x 10 125 34 14.0 11.0 16.5 18,20 MK2183H34 UNC 3/4" x 10 125 28 14.0 11.0 16.5 20,00
MK2183C78 UNC 7/8" x 9 9 140 34 18.0 14.5 19.5 28,50 MK2183H78 UNC 7/8" x 9 9 140 28 18.0 14.5 19.5 31,00
MK2183C1 UNC 1" x 8 160 38 20.0 14.5 22.2 34,50 MK2183H1 UNC 1" x 8 160 32 20.0 14.5 22.2 40,00
