81) Ě1&( 'ĚŃ .,/$98=/$5
'= .$1$/ 0$.ð1( .,/$98=8 81) ð1&( 'ðě r +(/ð6 .$1$/ 0$.ð1( .,/$98=8 81) ð1&( 'ðě
DIN-374/B DIN-374/C
HSS-M2AL HSS-M2AL
A (mm)
Ø 1 (mm) A (mm)
Ø 1 (mm)
35 °
Ø (mm)
L 1 (mm) Ø (mm)
L 1 (mm)
L (mm) L (mm)
60 ° 60 °
P P
B(3.5-5) C(2-3)
Ø (mm) Ø (mm)
KODU Ø x P L L 1 Ø 1 A KODU Ø x P L L 1 Ø 1 A
MK74DU14 UNF 1/4" x 28 28 80 15 4.5 3.4 5.5 4,90 MK74HF14 UNF 1/4" x 28 28 80 10 4.5 3.4 5.5 5,50
MK74DU516 UNF 5/16" x 24 90 18 6.0 4.9 6.9 5,40 MK74HF516 UNF 5/16" x 24 90 13 6.0 4.9 6.9 6,40
MK74DU38 UNF 3/8" x 24 24 90 20 7.0 5.5 8.5 6,60 MK74HF38 UNF 3/8" x 24 24 90 15 7.0 5.5 8.5 7,60
MK74DU716 UNF 7/16" x 20 100 20 8.0 6.2 9.9 6,70 MK74HF716 UNF 7/16" x 20 100 15 8.0 6.2 9.9 7,80
MK74DU12 UNF 1/2" x 20 20 100 21 9.0 7.0 11.5 7,80 MK74HF12 UNF 1/2" x 20 20 100 14 9.0 7.0 11.5 9,40
MK74DU916 UNF 9/16" x 18 100 21 11.0 9.0 12.9 9,10 MK74HF916 UNF 9/16" x 18 100 16 11.0 9.0 12.9 10,50
MK74DU58 UNF 5/8" x 18 18 100 21 12.0 9.0 14.5 10,20 MK74HF58 UNF 5/8" x 18 18 100 16 12.0 9.0 14.5 12,50
MK74DU34 UNF 3/4" x 16 110 24 14.0 11.0 17.5 19,70 MK74HF34 UNF 3/4" x 16 110 20 14.0 11.0 17.5 21,00
MK74DU78 UNF 7/8" x 14 14 125 24 18.0 14.5 20.5 28,60 MK74HF78 UNF 7/8" x 14 14 125 20 18.0 14.5 20.5 32,00
MK74DU1 UNF 1" x 12 140 26 18.0 14.5 23.2 35,00 MK74HF1 UNF 1" x 12 140 22 18.0 14.5 23.2 40,00
'= .$1$/ 3$5$/, 7$.,0 .,/$98= 81) ð1&( 'ðě
DIN-2181/B
Ø 1 (mm) A (mm)
HSS-M2AL Ø (mm)
L 1 (mm)
L (mm)
60 °
P
A(6-8)
60 °
P
C(2-3)
Ø (mm)
KODU Ø x P L L 1 Ø 1 A
MKF8114 UNF 1/4" x 28 28 50 16 6.0 4.9 5.5 5,90
MKF81516 UNF 5/16" x 24 56 22 6.0 4.9 6.9 6,70
MKF8138 UNF 3/8" x 24 24 63 20 7.0 5.5 8.5 8,00
MKF81716 UNF 7/16" x 20 63 20 8.0 6.2 9.9 10,00
MKF8112 UNF 1/2" x 20 20 70 22 9.0 7.0 11.5 12,00
MKF81916 UNF 9/16" x 18 70 22 11.0 9.0 12.9 14,00
MKF8158 UNF 5/8" x 18 18 70 22 12.0 9.0 14.5 16,50
MKF8134 UNF 3/4" x 16 80 22 14.0 11.0 17.5 26,00
MKF8178 UNF 7/8" x 14 14 80 22 18.0 14.5 20.5 36,00
MKF811 UNF 1" x 12 90 22 18.0 14.5 23.2 50,50
