METRİK KILAVUZLAR

DIN 376
Form C - 35° HELİS
MAKİNE KILAVUZU

DIN 376/C HSS HSS-E HSSE-TiN

Ø x P Ürün Kodu $ Ürün Kodu $ Ürün Kodu $
M3 x 0.5 280.0376.03050 7,40 281.0376.03050 8,30 282.0376.03050 9,50
M4 x 0.7 280.0376.04070 7,40 281.0376.04070 8,30 282.0376.04070 9,90
M5 x 0.8 280.0376.05080 7,40 281.0376.05080 8,30 282.0376.05080 10,30
M6 x 1 280.0376.06100 8,40 281.0376.06100 10,20 282.0376.06100 12,60
M8 x 1.25 280.0376.08125 9,80 281.0376.08125 11,80 282.0376.08125 15,00
M10 x 1.5 280.0376.10150 12,80 281.0376.10150 16,40 282.0376.10150 20,40
M12 x 1.75 280.0376.12175 14,40 281.0376.12175 18,80 282.0376.12175 23,50
M14 x 2 280.0376.14200 15,50 281.0376.14200 20,30 282.0376.14200 25,80
M16 x 2 280.0376.16200 17,10 281.0376.16200 23,10 282.0376.16200 29,40
M18 x 2.5 280.0376.18250 19,20 281.0376.18250 26,10 282.0376.18250 33,20
M20 x 2.5 280.0376.20250 24,00 281.0376.20250 29,20 282.0376.20250 37,00
M22 x 2.5 280.0376.22250 27,70 281.0376.22250 37,20 282.0376.22250 45,80
M24 x 3 280.0376.24300 34,60 281.0376.24300 44,20 282.0376.24300 53,60
M27 x 3 280.0376.27300 42,60 281.0376.27300 56,20 282.0376.27300 66,80
M30 x 3.5 280.0376.30350 52,20 281.0376.30350 72,80 282.0376.30350 84,50
M33 x 3.5 280.0376.33350 69,20 281.0376.33350 92,90 282.0376.33350 105,80
M36 x 4 280.0376.36400 84,60 281.0376.36400 112,40 282.0376.36400 126,50
M39 x 4 280.0376.39400 100,00 281.0376.39400 132,50 282.0376.39400 147,80
M42 x 4.5 280.0376.42450 111,20 281.0376.42450 145,60 282.0376.42450 162,00
M45 x 4.5 280.0376.45450 168,60 281.0376.45450 205,30 282.0376.45450 222,90
M48 x 5 280.0376.48500 191,10 281.0376.48500 231,90 282.0376.48500 250,60
M52 x 5 280.0376.52500 225,90 281.0376.52500 278,10 282.0376.52500 298,40
