DIN-212/D 8° 62/ +(/6 DIN-208/B 8° 62/ +(/6
KESME KESME
TOLERANSI H7 TOLERANSI H7
Ø (mm) Ø 1 (mm) Ø (mm) MK
L 1 (mm)
L 2 (mm) L 1 (mm)
L (mm) L (mm)
6$Â 6$Â
KODU Ø Ø 1 L L 1 L 2 KODU Ø L L 1 MK
=05 3.0 mm 3.0 61 15 25 5,30 =05 5 mm 133 23 1 15,80
=05 3.5 mm 3.5 70 18 29 5,30 =05 6 mm 138 26 1 16,00
=05 4.0 mm 4.0 75 19 32 5,40 =05 7 mm 150 31 1 16,20
=05 4.5 mm 4.5 80 21 33 5,50 =05 8 mm 156 33 1 16,40
=05 5.0 mm 5.0 86 23 34 5,60 =05 9 mm 162 36 1 16,60
=05 5.5 mm 5.6 93 26 38 5,80 =05 10 mm 168 38 1 17,00
=05 6.0 mm 5.6 93 26 38 5,80 =05 11 mm 175 41 1 17,70
=05 7.0 mm 7.1 109 31 40 6,10 =05 12 mm 182 44 1 18,80
=05 8.0 mm 8.0 117 33 42 7,10 =05 13 mm 182 44 1 19,90
=05 9.0 mm 9.0 125 36 44 8,70 =05 14 mm 189 47 1 21,00
=05 10.0 mm 10.0 133 38 46 9,50 =05 15 mm 204 50 2 22,10
=05 11.0 mm 10.0 142 41 46 13,90 =05 16 mm 210 52 2 23,30
=05 12.0 mm 10.0 151 44 46 15,80 =05 17 mm 214 54 2 24,30
=05 13.0 mm 10.0 151 44 46 16,30 =05 18 mm 219 56 2 25,50
=05 14.0 mm 12.5 160 47 50 17,70 =05 19 mm 223 58 2 26,50
=05 15.0 mm 12.5 162 50 50 21,00 =05 20 mm 228 60 2 27,70
=05 16.0 mm 12.5 170 52 50 22,10 =05 21 mm 232 62 2 29,90
=05 17.0 mm 14.0 175 54 52 24,30 =05 22 mm 237 64 2 30,90
=05 18.0 mm 16.0 182 56 52 27,70 =05 23 mm 241 66 2 33,10
=05 19.0 mm 16.0 189 58 58 28,70 =05 24 mm 268 68 3 36,50
=05 20.0 mm 16.0 195 60 58 30,90 =05 25 mm 268 68 3 38,70
=05 26 mm 273 70 3 39,70
=05 27 mm 277 71 3 41,90
=05 28 mm 277 71 3 44,10
=05 29 mm 281 73 3 48,60
=05 30 mm 285 75 3 55,20
=05 32 mm 317 77 4 71,80
=05 34 mm 321 78 4 93,80
=05 35 mm 321 78 4 104,80
=05 36 mm 325 79 4 110,30
=05 38 mm 329 81 4 115,90
=05 40 mm 329 81 4 121,30
=05 42 mm 333 82 4 132,30
=05 45 mm 336 83 4 146,70
